High-Performance 160A IGBT Inverter HF Digital Plasma Cutting Machine from China Suppliers and Factory
Detailed Information
Plasma cutting machine is a machine for processing metal materials by means of plasma cutting technology. Plasma cutting is a processing method that uses the heat of the high-temperature plasma arc to partially or partially melt (and evaporate) the metal at the incision of the workpiece, and uses the momentum of the high-speed plasma to exclude the molten metal to form a cut.
Main Features
Working Connection Diagram
Product Parameters
| Model | LGK-160 |
| Rated Input Voltage | 380V 50Hz/60Hz |
| Rated Input Power | 23.6Kva |
| No Load Voltage | 340V |
| Current Regulation | 25-160A |
| Output Current | 160A |
| Load Duration | 60% |
| Cutting Thickness | 55mm |
| Insulation Class | F |
| Striking Mode | HG No-contact |
| Dimensions | 61*30.5*58cm |
| Weight | 43Kg |
Installation Attentions
Standard Accessories
1x Electrode Holder
1x Ground Clamp
1x Welding Mask
1x Brush/Hammer
Optional Accessories
Welding Helmet
Welding Gloves
Electrodes E6013
Lift TIG TORCH
Frequently Asked Questions
Q1: What is the maximum cutting thickness of the LGK-160 plasma cutting machine?
A1: The LGK-160 plasma cutting machine has a maximum cutting thickness capability of 55mm.
Q2: What are the input voltage requirements for installation?
A2: The machine requires a rated input voltage of 380V AC±10% at a frequency of 50/60Hz.
Q3: How does the non-contact high-frequency arc ignition benefit the cutting process?
A3: The non-contact high-frequency arc ignition ensures a high arc ignition success rate and minimizes electromagnetic interference during operation.
Q4: What is the current regulation range for the LGK-160?
A4: The cutting current is precisely and infinitely adjustable within the range of 25A to 160A, making it suitable for workpieces of various thicknesses.
Q5: What are the recommended environmental conditions for operating this machine?
A5: It should be operated in ambient temperatures between -10℃ and +40℃. Ensure the air inlets and outlets are not blocked, avoid direct sunlight exposure, and protect the unit from dust accumulation.
Q6: What standard accessories are included in the package?
A6: The standard package includes 1x Electrode Holder, 1x Ground Clamp, 1x Welding Mask, and 1x Brush/Hammer.
