IGBT Air Compressor with Upgraded Features from China Factory - Reliable Suppliers for HF ARC Plasma Cutter
Detailed Information
The advantages of the plasma cutting machine are that the plasma arc energy is more concentrated, the temperature is more localized, the cutting speed is faster, the deformation is smaller, and it can cut stainless steel, aluminum and other materials. Plasma cutting machine has the advantage of cutting thick plates, because the cutting speed is much higher than laser and flame.
The plasma arc can cut various metals, such as stainless steel, heat-resistant steel, titanium, molybdenum, tungsten, cast iron, copper, aluminum and aluminum alloy. Cutting stainless steel. Aluminum thickness up to 200mm or more.
The plasma arc cutting speed is faster, and the production is relatively partial.
When cutting the plasma arc, you can get a relatively narrow radian, clean, tidy, no sticky residue, close to vertical incision, small incision deformation and thermal influence, small change in hardness, and good cutting quality.
Main Features
- All welding machines use new electronic components.
- Industrial-grade dual-module configuration, large current and strong cutting ability.
- High load endurance, suitable for longtime cutting operations.
- Non-contact high-frequency arc ignition, high arc ignition success rate and low interference.
- With manual welding function.
- Humanized and elegant appearance design, more convenient to operate.
- Three-proof design for key parts, suitable for various harsh environments, stable and reliable operation.
Product Parameters
| Model | LGK-70F | LGK-100F | LGK-130F | LGK-160F |
|---|---|---|---|---|
| Rated Input Voltage | AC220V/380V 50Hz/60Hz | AC 3P 380V 50Hz/60Hz | ||
| Rated Input Power | 10Kva | 12Kva | 17Kva | 24Kva |
| No Load Voltage | 330V | 340V | 340V | 340V |
| Current Regulation | 20-70A | 20-100A | 20-130A | 20-160A |
| Output Current | 70A | 100A | 130A | 160A |
| Load Duration | 60% | 60% | 60% | 60% |
| Cutting Thickness | 20mm | 30mm | 35mm | 40mm |
| Striking Mode | HF Non-contact | HF Non-contact | HF Non-contact | HF Non-contact |
| Insulation Class | F | F | F | F |
| Dimensions | 49*24*42cm | 60*36*55cm | 60*36*55cm | 64*39*63cm |
| Weight | 26.5Kg | 39Kg | 40Kg | 55Kg |
Installation Attentions
Standard Accessories
Optional Accessories
